AXGD-1354-0533
Gigabit Ethernet Series: 1250 Mbps, 1310 nm, Single-mode, 10km
- 1250 Mbps data rate
- 1310 nm wavelenght
- FP Light source
- Single-mode
- -9.5 Tx Power
- -20 Max dBm Rx Sens.
- 10.5 dBm Link budget
- -3 dBm saturation
- 10km distance
- Operating temperature from -40° to 85° C
- UL/TUV certified
| Gigabit Ethernet Series | ||
|---|---|---|
| MODEL NAME | PART NUMBER | DESCRIPTION |
| AXGD-5854-0513 | 522AXGD5854001G | 1250Mbps, 850nm, Multi-mode, 550m, 3.3V, -40°C to +85°C, DDMI |
| AXGD-1354-0523 | 522AXGD1354001G | 1250Mbps, 1310nm, Multi-mode, 2km, 3.3V, -40°C to +85°C, DDMI |
| AXGD-1354-0533 | 522AXGD1354011G | 1250Mbps, 1310nm, Single-mode, 10km, 3.3V, -40°C to +85°C, DDMI |
| AXGD-3354-0593 | 522AXGD3354001G | 1250Mbps, 1310nm, Single-mode, 40km, 3.3V, -40°C to +85°C, DDMI |
