AXFD-1314-0523

Fast Ethernet Series: 125 / 155 Mbps, 1310 nm, Multi-mode, 2km

  • 125 / 155 Mbps data rate
  • 1310 nm wavelenght
  • FP Light source
  • Multi-mode
  • -20 dBm Tx Power
  • -32 Max dBm Rx Sens.
  • 12 dBm Link budget
  • -14 dBm saturation
  • 2km distance
  • Operating temperature from -40° to 85° C
  • UL/TUV certified



Fast Ethernet Series
MODEL NAME PART NUMBER DESCRIPTION
AXFD-1314-0523 522AXFD1314001G 125 to 155Mbps, Multi-mode, 1310nm, 2km, -40°C to +85°C, DDMI
AXFD-1314-0553 522AXFD1314011G 155Mbps, Single-mode, 1310nm, 30km, -40°C to +85°C, DDMI

Datasheet

VERSION NAME TIME SIZE DOWNLOAD
v1.0 Datasheet EN 2024-04-23 294.37 KB
1 older version
